background image
Preliminary Data Sheet
BCM5222
7/20/04
Broadcom Corporation
Document 5222-DS02-405-R
Auto-Negotiation Link Partner (LP) Next Page Transmit Register
Page 27
ACKNOWLEDGE 2
Indicates that a device has the ability to comply with the message.
TOGGLE
Used by the Arbitration function to ensure synchronization with the link partner during next page exchange.
MESSAGE CODE FIELD
An 11-bit-wide field, encoding 2048 possible messages.
UNFORMATTED CODE FIELD
An 11-bit-wide field, which may contain an arbitrary value.
AUTO-NEGOTIATION LINK PARTNER (LP) NEXT PAGE TRANSMIT
REGISTER
NEXT PAGE
Indicates whether this is the last next page.
Table 14: Next Page Transmit Register (Address 08d, 08h)
Bit
Name
R/W
Description
Default
15
Next Page
RO
1 = Additional next page(s) will follow
0 = Last page
0
14
Reserved
RO
Ignore when read
0
13
Message Page
RO
1= Message page
0 = Unformatted page
0
12
Acknowledge 2
RO
1 = Will comply with message
0 = Cannot comply with message
0
11
Toggle
RO
1 = Previous value of the transmitted link code word
equalled logic zero
0 = Previous value of the transmitted link code word
equalled logic one
0
10:0
Message/Unformatted Code
Field
RO
0
Note: R/W = Read/Write, RO = Read only, SC = Self Clear, LL = Latched Low, LH = Latched High, LL & LH Clear after
read operation. Use default values of reserved bit(s) when writing to reserved bit(s).
