AD9739

Data Sheet

Rev. E | Page 14 of 50

fDAC = 2 GSPS, IOUTFS = 20 mA, nominal supplies, 25°C, unless otherwise noted.

–3dBFS

0dBFS

fOUT (MHz)

100 200 300 400 500 600 700 800 900 1000

–6dBFS

Figure 13. SFDR vs. fOUT over Digital Full Scale

fOUT (MHz)

100 200 300 400 500 600 700 800 900 1000

0dBFS

–3dBFS

–6dBFS

Figure 14. SFDR for Second Harmonic over fOUT vs. Digital Full Scale

fOUT (MHz)

100 200 300 400 500 600 700 800 900 1000

10mA FS

20mA FS

30mA FS

Figure 15. SFDR vs. fOUT over DAC IOUTFS

fOUT (MHz)

100

110

100 200 300 400 500 600 700 800 900 1000

0dBFS

–6dBFS

–3dBFS

Figure 16. IMD vs. fOUT over Digital Full Scale

fOUT (MHz)

100 200 300 400 500 600 700 800 900 1000

–6dBFS

–3dBFS

0dBFS

Figure 17. SFDR for Third Harmonic over fOUT vs. Digital Full Scale

fOUT (MHz)

100

110

100 200 300 400 500 600 700 800 900 1000

10mA FS

20mA FS

30mA FS

Figure 18. IMD vs. fOUT over DAC IOUTFS
