ADRF6612
Data Sheet
Rev. A | Page 48 of 57
Address: 0x44, Reset: 0x0000, Name: SYNTH_FCNTN_CTRL
Table 39. Bit Descriptions for SYNTH_FCNTN_CTRL
Bits
Bit Name
Settings
Description
Reset
Access
[15:6]
UNUSED
Unused
0x0
RW
5
DIV_SDM_DIS
Disable SDM divider
0x0
RW
4
VCOCNT_CG_DIS
Disable BIST clock
0x0
RW
3
BANDCAL_CG_DIS
Disable bandcal clock
0x0
RW
2
SDM_CG_DIS
Disable SDM clock
0x0
RW
1
SDM_DIVD_CLR
SDM_DIVD_CLR
0x0
RW
0
BANDCAL_DIVD_CLR
BANDCAL_DIVD_CLR
0x0
RW
Address: 0x45, Reset: 0x0020, Name: VCO_CTRL2
Table 40. Bit Descriptions for VCO_CTRL2
Bits
Bit Name
Settings
Description
Reset
Access
[15:8]
UNUSED
Unused
0x0
RW
7
VCO_BAND_SRC
Set VCO band source
0x0
RW
0
Automatic
1
Manual
[6:0]
BAND
Set VCO band
0x20
RW
