background image
Data Sheet
ADP5360
Rev. 0 | Page 11 of 60
Ball No.
Mnemonic
Description
E1
SW1
Switching Node for Buck Regulator.
E2
EN1
Hardware Enable for Buck Regulators.
E3
RESET
Reset Output.
E4
MR
Manual Reset Input.
E5
ICS
Set Charge Current. Connect one resistor to ground to set the default charge current. Float the pin to disable the
pin select feature and use the register default set.
E6
VSYS
Linear Charger, Supply Side Input to the Internal Isolation FET.
F1
PGND1
Power Ground for the Buck Regulator.
F2
VIN1
Input Power for the Buck Regulator.
F3
ENCHG
Logic Input for the Enable Charger Function.
F4
AGND1
Analog Ground.
F5
VDD
Internal Circuit Power Supply.
F6
VBUS
Power Connection to USB VBUS.
