15
Microcomputer Peripheral LSIs
MN1380 Series
V
V
VSS
OUT
VDD
V
V
VSS
OUT
VDD
4.8
4.6
4.4
4.2
4.0
3.8
3.6
3.4
–40
–20
0
20
40
60
80
Temperature Ta(˚C)
Ambient temperature, Ta (˚C)
0.3
0.25
0.2
0.15
0.1
0.05
0
–40
–20
0
20
40
60
80
V
DH
V
DL
Reference Characteristics (continued)
Figure 7.a. VDL/VDH Temperature Characteristic (Rank Q)
Figure 7.b. Measurement Circuit
Figure 8.a.
∆VD Temperature Characteristic (Rank Q)
Figure 8.b. Measurement Circuit
