ADP5140
Data Sheet
Rev. 0 | Page 84 of 128
Bits
Bit Name
Description
Reset
Access
5
VOUT10_OT_RST_MASK
Mask the VOUT10_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
4
VOUT9_OT_RST_MASK
Mask the VOUT9_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
3
VOUT8_OT_RST_MASK
Mask the VOUT8_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
2
VOUT7_OT_RST_MASK
Mask the VOUT7_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
1
VOUT6_OT_RST_MASK
Mask the VOUT6_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
0
VOUT5_OT_RST_MASK
Mask the VOUT5_OT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
Table 61. OTHER_RST_MASK, Register Address: 0x2044
Bits
Bit Name
Description
Reset
Access
[31:29]
RESERVED
Reserved.
0x0
R
28
WDI1_EXT_RST_MASK
Mask the WDI1_EXT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
27
WDI0_EXT_RST_MASK
Mask the WDI0_EXT_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
26
VSET1_DETECTION_RST_MASK
Mask the VSET1_DETECTION_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
25
MODE_DETECTION_RST_MASK
Mask the MODE_DETECTION_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
24
SYNC_FAIL_RST_MASK
Mask the SYNC_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
23
WDI1_PULSE_FAIL_RST_MASK
Mask the WDI1_PULSE_STATUS Bit on the RESET Pin.
0x0
R/W
0: mask.
1: not mask.
