79 / 132 page  DS10688 Rev 7 79/132 STM32L082xx Electrical characteristics 109 6.3.8 PLL characteristics The parameters given in Table 48 are derived from tests performed under ambient temperature and VDD supply voltage conditions summarized in Table 23. tSTAB(MSI)(2) MSI oscillator stabilization time MSI range 0 - 40 µs MSI range 1 - 20 MSI range 2 - 10 MSI range 3 - 4 MSI range 4 - 2.5 MSI range 5 - 2 MSI range 6, Voltage range 1 and 2 -2 MSI range 3, Voltage range 3 -3 fOVER(MSI) MSI oscillator frequency overshoot Any range to range 5 -4 MHz Any range to range 6 -6 1. This is a deviation for an individual part, once the initial frequency has been measured. 2. Guaranteed by characterization results. Table 47. MSI oscillator characteristics (continued) Symbol Parameter Condition Typ Max Unit Table 48. PLL characteristics Symbol Parameter Value Unit Min Typ Max(1) 1. Guaranteed by characterization results. fPLL_IN PLL input clock(2) 2. Take care of using the appropriate multiplier factors so as to have PLL input clock values compatible with the range defined by fPLL_OUT. 2- 24 MHz PLL input clock duty cycle 45 - 55 % fPLL_OUT PLL output clock 2 - 32 MHz tLOCK PLL input = 16 MHz PLL VCO = 96 MHz - 115 160 µs Jitter Cycle-to-cycle jitter - ±600 ps IDDA(PLL) Current consumption on VDDA - 220 450 µA IDD(PLL) Current consumption on VDD - 120 150 |
|
