Description

STM32L082xx

10/132

DS10688 Rev 7

Description

The ultra-low-power STM32L082xx microcontrollers incorporate the connectivity power of

the universal serial bus (USB 2.0 crystal-less) with the high-performance Arm Cortex-M0+

32-bit RISC core operating at a 32 MHz frequency, a memory protection unit (MPU), high-

speed embedded memories (up to 192 Kbytes of Flash program memory, 6 Kbytes of data

EEPROM and 20 Kbytes of RAM) plus an extensive range of enhanced I/Os and

peripherals.

The STM32L082xx devices provide high power efficiency for a wide range of performance.

It is achieved with a large choice of internal and external clock sources, an internal voltage

adaptation and several low-power modes.

The STM32L082xx devices offer several analog features, one 12-bit ADC with hardware

oversampling, two DACs, two ultra-low-power comparators, AES, several timers, one low-

power timer (LPTIM), four general-purpose 16-bit timers and two basic timer, one RTC and

one SysTick which can be used as timebases. They also feature two watchdogs, one

watchdog with independent clock and window capability and one window watchdog based

on bus clock.

Moreover, the STM32L082xx devices embed standard and advanced communication

interfaces: up to three I2Cs, two SPIs, one I2S, four USARTs, a low-power UART

(LPUART), and a crystal-less USB. The devices offer up to 19 capacitive sensing channels

to simply add touch sensing functionality to any application.

The STM32L082xx also include a real-time clock and a set of backup registers that remain

powered in Standby mode.

The ultra-low-power STM32L082xx devices operate from a 1.8 to 3.6 V power supply (down

to 1.65 V at power down) with BOR and from a 1.65 to 3.6 V power supply without BOR

option. They are available in the -40 to +125 °C temperature range. A comprehensive set of

power-saving modes allows the design of low-power applications.
