DS10688 Rev 7

115/132

STM32L082xx

Package information

126

Figure 38. UFQFPN48 – Recommended footprint

1. Dimensions are expressed in millimeters.

Table 79. UFQFPN48 – Mechanical data

Symbol

millimeters

inches(1)

1. Values in inches are converted from mm and rounded to 4 decimal digits.

Min

Typ

Max

Min

Typ

Max

0.500

0.550

0.600

0.0197

0.0217

0.0236

0.000

0.020

0.050

0.0000

0.0008

0.0020

0.152

0.0060

0.200

0.250

0.300

0.0079

0.0098

0.0118

D(2)

2. Dimensions D and E do not include mold protusion, not exceed 0.15 mm.

6.900

7.000

7.100

0.2717

0.2756

0.2795

5.400

5.500

5.600

0.2126

0.2165

0.2205

D2(3)

3. Dimensions D2 and E2 are not in accordance with JEDEC.

5.500

5.600

5.700

0.2165

0.2205

0.2244

E(2)

6.900

7.000

7.100

0.2717

0.2756

0.2795

5.400

5.500

5.600

0.2126

0.2165

0.2205

E2(3)

5.500

5.600

5.700

0.2165

0.2205

0.2244

0.500

0.0197

0.300

0.400

0.500

0.0118

0.0157

0.0197

0.152

0.0060

ddd

0.080

0.0031

7.30

0.20

0.30

0.55

0.50

5.80

6.20

5.60

5.80

0.75

A0B9_UFQFPN48_FP_V3
