6 / 226 page  KSZ9563R DS00002419D-page 6 2017-2018 Microchip Technology Inc. 1.2 Buffer Types TABLE 1-2: BUFFER TYPES Buffer Type Description I Input IPU Input with internal pull-up (58 k ±30%) IPU/O Input with internal pull-up (58 k ±30%) during power-up/reset; output pin during normal operation IPD Input with internal pull-down (58 k ±30%) IPD/O Input with internal pull-down (58 k ±30%) during power-up/reset; output pin during normal operation O8 Output with 8 mA sink and 8 mA source O24 Output with 24 mA sink and 24 mA source OPU Output (8mA) with internal pull-up (58 k ±30%) OPD Output (8mA) with internal pull-down (58 k ±30%) A Analog AIO Analog bidirectional ICLK Crystal oscillator input pin OCLK Crystal oscillator output pin P Power GND Ground Note: Refer to Section 6.3, "Electrical Characteristics," on page 196 for the electrical characteristics of the vari- ous buffers. |
|
