P9415-R Datasheet
© 2021 Renesas Electronics Corporation
46
May 4, 2021
Address
and Bit
Register Field Name
R/W
Default
Value
Function and Description
0x32 [1:0]
Reserved
R
0
Reserved
0x31 [7]
VSWITCHFAILED
R
0
1 = Indicates the voltage switch command is failed.
0 = No such condition
0x31 [6]
SLEEPMODE
R
0
1 = Indicates the Rx is in sleep mode
0 = No such condition
0x31 [5]
IDAUTHSUCCESS
R
0
1 = Indicates the ID authentication is passed
0 = No such condition
0x31 [4]
IDAUTHFAILED
R
0
1 = Indicates the ID authentication is failed
0 = No such condition
0x31 [3]
BCSUCCESS
R
0
1 = Indicates the backchannel packet is received by Tx
0 = No such condition
0x31 [2]
BCTIMEOUT
R
0
1 = Indicates the backchannel packet is sending failed.
0 = No such condition
0x31 [1]
TXAUTHSUCCESS
R
0
1 = Indicates the Device authentication is passed.
0 = No such condition
0x31 [0]
TXAUTHFAILED
R
0
1 = Indicates the Device authentication is failed.
0 = No such condition
0x30 [7]
LDODISABLE
R
0
1 = Indicates the LDO is disabled
0 = No such condition
0x30 [6]
LDOENABLE
R
0
1 = Indicates the LDO is enabled
0 = No such condition
0x30 [5]
MODECHHGED
R
0
1 = Indicates the work mode of P9415 is changed
0 = No such condition
0x30 [4]
TXDATARCVD
R
0
1 = Indicates the proprietary packet from Tx is received.
0 = No such condition
0x30 [3]
VSWITCHSUCCESS
R
0
1 = Indicates the voltage switch command is successful.
0 = No such condition
0x30 [2]
OVERTEMP
R
0
1 = Indicates the die temperature exceeds the OTP threshold.
0 = No such condition
0x30 [1]
OVERVOLT
R
0
1 = Indicates the voltage on Vrect exceeds the OVP threshold
0 = No such condition
0x30 [0]
OVERCURR
R
0
1 = Indicates the current exceeds the OCP threshold.
0 = No such condition
Note: The bit definition in Rx mode and Tx mode is different.
