3. Absolute Maximum Ratings

The absolute maximum ratings are stress ratings only. Stresses greater than those listed below can cause permanent damage to the device.

Functional operation of the P9415-R at absolute maximum ratings is not implied. Exposure to absolute maximum rating conditions may affect

device reliability.

Table 2.

Absolute Maximum Ratings

Symbol/Pins

Parameter

Minimum

Maximum

Units

TJ

Junction temperature

-

150

°C

TS

Storage temperature

-55

150

°C

HBM

ESD – Human Body Model

-

2000

V

CDM

ESD – Charged Device Model

-

500

V

CMA, CMB, COM1, COM2, PCLAMP, VRECT, AC1, AC2

Maximum voltage

-0.3

26.5

V

BST1, BST2

Maximum voltage

-0.3

AC1+5, AC2+5

V

LDO1P8, GP0-GP6

Maximum voltage

-0.3

2

V

LDO5P0, DEMOD, nEN, ECLAMP_DRV, OD0-OD4

Maximum voltage

-0.3

6

V

PGND

Maximum voltage

-0.3

0.3

V

VOUT

Maximum voltage

-0.3

21

V

CMA, CMB, COM1, COM2

Maximum RMS current

500

mA

AC1, AC2

Maximum RMS current

2

A

VOUT Output Current

Maximum RMS current

1.9

A

4. Thermal Characteristics

Table 3.

Thermal Characteristics[a][b][c][d]

Symbol

Parameter

Value

Units

θJA

Theta JA. Junction to ambient.

45

°C/W

θJB

Theta JB. Junction to board.

4.36

°C/W

θJC

Theta JC. Junction to case.

0.2

°C/W

-

Moisture Sensitivity Rating (Per J-STD-020)

MSL 1

-

[a] The maximum power dissipation is PD(MAX) = (TJ(MAX) - TA) / θJA where TJ(MAX) is 125°C. Exceeding the maximum allowable power dissipation will

result in excessive die temperature, and the device will enter thermal shutdown.

[b] This thermal rating was calculated on JEDEC 51 standard 4-layer board with dimensions 3” x 4.5” in still air conditions.

[c] Actual thermal resistance is affected by PCB size, solder joint quality, layer count, copper thickness, air flow, altitude, and other unlisted variables.

[d] For the WLCSP (AWQ53) package, connecting 8 PGND balls and at least two other CSP balls (10 thermal balls total) to internal/external ground

planes from top to bottom sides of the PCB is recommended for improving the overall thermal performance.
