P9415-R Datasheet

May 4, 2021

Table 58. Read Data Register for WPC 1.3 (0x196)

Address

and Bit

R/W

Default

Value

Function and Description

0x196[15:0]

ccRdSize

Length of the raw data received from Tx

Procedure of WPC1.3 bi-di communication

1. Clear interrupt.

2. AP writes raw data to Write Data Register (0x1A4).

3. AP writes type and data length to Write Data Type and Length Register (0x1A0, 2 bytes).

4. AP writes command 0x02 to system command register (0x4F, 1 byte) to send the data out.

5. AP waits for interrupt (ADTRCVD).

6. AP reads received data length from Read Data Register (0x196, 2 bytes).

7. AP reads received data from Read Data Register (0x3A4).
