Table 12. DC characteristics (M24C01/02-W)

Symbol

Parameter

Test conditions (in addition to those in Table 5 and Table 8)

Min.

Max.

Unit

ILI

Input leakage current

(Ei, SCL, SDA)

VIN = VSS or VCC, device in standby mode

-

± 2

µA

ILO

Output leakage current SDA in Hi-Z, external voltage applied on SDA: VSS or VCC

-

± 2

µA

ICC

Supply current (Read)

fC = 400 kHz

2.5 V ≤ VCC ≤ 5.5 V

-

1

mA

ICC0(1) Supply current (Write)

During tW,

2.5 V ≤ VCC ≤ 5.5 V

-

0.5

mA

ICC1

Standby supply current

Device not selected(2),

VIN = VSS or VCC, VCC = 2.5 V

-

2

μA

Device not selected(2),

VIN = VSS or VCC, VCC = 5.5 V

-

3

μA

VIL

Input low voltage

(SCL, SDA, WC)

-

–0.45

0.3 VCC

V

VIH

Input high voltage

(SCL, SDA, WC)

-

0.7 VCC VCC+1

V

VOL

Output low voltage

IOL = 2.1 mA, VCC = 2.5 V or

IOL = 3 mA, VCC = 5.5 V

-

0.4

V

1. Evaluated by characterization - Not tested in production.

2. The device is not selected after power-up, after a read instruction (after the stop condition), or after the completion of the

internal write cycle tW (tW is triggered by the correct decoding of a write instruction).
