Table 5. Pin Description (Continued)

Pins

Name

Typical Description

TS1

G5

Remote temperature sensor 1. If not used, connect to AGND.

SDA

H2

I/O

I2C data pin. Open drain output. Connect a 5.1 K resistor from this pin to VDD.

SCL

H3

I

I2C clock pin. Open drain output. Connect a 5.1 K resistor from this pin to VDD.

INT

H4

O

Fault interrupt flag pin. It is an open-drain output that signals fault interrupts. It pulls low

when EN is high, EOC is high, die temperature reaches 130°C, TS1, or TS2 are triggered.

ACT

H5

O

Active flag pin. Open drain output. Connect the cathode of the LED to this pin. When pulled

low, it indicates connection between receiver and transmitter is established.
