T is the temperature in Kelvin.

R0 is the known resistance at calibration temperature T0.

B (beta) is the material constant.

The ADC reading of thermistors TS1 and TS2 can be monitored by the I2C interface. The ADC value can be calculated using the thermistor

resistance formula and the following:

255

1.8V

A

10

100

R

ADC

-6

TS









Recommended Coils

The following coils are recommended with P9027LP-R receiver for 1, 2 and 3 W applications for optimum performance. The recommended

vendors have been tested and verified.

Table 9. Coils Recommended with Receiver for 1, 2 and 3 W Applications.

Output Power

Vendor

Part Number

Inductance

DCR

Dimension

1 W

TDK

WR121220-27M8-ID

8.32 uH

0.98 Ω

Ø12 mm

SunLord

SWA12R12H08C01B

8.50 uH

0.38 Ω

Ø12 mm

2 W

TDK

WR202010-18M8-ID3

11.0 µH

0.40 Ω

Ø20 mm

Wurth Electronics

760308101220

12.60 µH

0.27 Ω

Ø17 mm

SunLord

SWA20R20H08C01B

12.0 µH

0.29 Ω

20 mm x 20 mm

3 W

TDK

WR303050-12F5-ID1

8.20 µH

0.30 Ω

30 mm x 30 mm

Wurth Electronics

760308102213

7.90 µH

0.26 Ω

29 mm x 29 mm

SunLord

SWA30R30H08C01B

8.20 uH

0.33 Ω

30 mm x 30 mm

PCB Layout Consideration

For optimum device performance and lowest output phase noise, IDT recommends that customers copy the reference layout used in the

P9027LP-R-EVK reference kit. More information and layout files can be found at http://www.idt.com/WP3W-RK.

Additional layout guidelines can be found in application note AN-933. Users are encouraged to read this document prior to starting a board

design.
