11. Functional Registers

The following tables provide address locations, field names, available operations (R or RW), default values, and functional descriptions of all

internally accessible registers contained within the P9242-R3. The default I2C slave address is 61HEX.

Table 12. State Register

Address and Bits

Register Field Name

R/W

Default

Function and Description

06E0HEX

System_State

R

00HEX

0DEC = Startup

1DEC = Idle

2DEC = Analog Ping Phase

4DEC = Digital Ping Phase

5DEC = WPC Identification

7DEC = WPC Configuration

8DEC = Power Transfer Initialization

9DEC = Power Transfer State

11DEC = Remove Power

12DEC = Restart

13DEC = WPC Negotiation

Table 13. Status Register

Address and Bits

Register Field Name

R/W

Default

Function and Description

06E1HEX

System_Status

R

00HEX

0DEC = System Normal

1DEC = FOD Alarm

2DEC = EPT Charge Complete

4DEC = EPT No Response

5DEC = EPT Internal Fault

6DEC = Over-Temperature Alarm

7DEC = Over-Current

9DEC = EPT Other Rx Fault

10DEC = Negotiation Fail

Table 14. Read Register – Coil Current

Address and Bits

Register Field Name

R/W

Default

Function and Description

06E2HEX [7:0]

Coil_current [7:0]

R

–

8 LSB of coil current value in mA.

06E3HEX [7:0]

Coil_current [15:8]

R

–

8 MSB of coil current value in mA.
