12.2 Recommended Coils

Table 26. Recommended Coil Manufactures

Output Power

Vendor

Part number

Inductance at 100kHz

DCR at 20°C

15W

SUNLORD

SWA53N53H30C11B

10µH

50mΩ

15W

TDK

WT525225-12F2-MA2-G

10.6µH

40mΩ

15W

WURTH

760308103102

10µH

55mΩ

12.3 Typical Application Schematic – P9242-R3-EVK included in WP15WBD-RK Kit

Note: The typical application schematic provides a basic guideline to understanding and building a functional medium-power wireless power

transmitter type MP-A2 as described in the WPC specifications. Other components, not shown on the typical application schematic, might be

needed in order to comply with other requirements, such as EMC or thermal specifications.
