One object that has both button and lamp

functions can be created. This eliminates the

need for creating multiple objects, helping

create screens faster.

A lamp (indicator) can be set on a button.

Buttons with the lamp function

You can easily create Buttons with the lamp function.

Setting

Condition for lightning lamps

Touch(Button)

Pressing Button

Variable(Button)

Variable

Feedback(Button)

Feedback Expression

Touch(Button)

+Feedback(Button)

Pressing Button + Feedback

Expression

Touch(Button)

+Feedback(Indicator)

Button: Pressing Button

Indicator: Feedback Expression

Variable(Button)

+Feedback(Indicator)

Button: Variable

Indicator: Feedback Expression

■Types of Buttons with the lamp function

■Example

■Conceptual figure for setting objects

Page Editor

Provides a simple GUI and a full suite of functionality to assist and streamline the design process.

No need to recreate the button to change its type. The settings will be maintained even

the type has been changed, reducing the amount of work required for screen creation.

Changing type of button

The type of the Buttons including Set and Momentary can be changed easily in the properties

whenever you want, even during or after designing the Button.

Importing and exporting pages

Pages can be saved as library files and reused individually in other projects.

Save and manage as library file

Import to reuse
