Programmable Terminal

NA series

Bringing technology to life

The NA-series Programmable Terminal transforms machine data

into information, shows information and controls devices based on

requirements at FA manufacturing sites.

The NA Series, together with the NJ/NX/NY-series Controller and

the Automation Software Sysmac Studio, allows you to simply and

flexibly create sophisticated user interfaces to suit your machines.

Features

• Widescreen in all models: 7, 9, 12, and 15 inches

• More than 16 million color display for all models and 1280 x 800 high resolution display for the 12 and 15-inch models

• Multimedia including video and PDF *1

• 2 Ethernet ports capable of simultaneous access from both the control device and maintenance segments by separating the segments

• Sysmac Studio providing an Integrated Development Environment

NJ/NX/NY variables sharing in the NA project and NA application testing with the NJ/NX/NY program via the Simulator to reduce development

time

• Many security features including operation authority settings and execution restrictions with IDs

• Microsoft Visual Basic for versatile, flexible and advanced programming

• Software providing NA5-equivalent functionality on a PC or panel PC

*1. Version 1.5 or higher of pdf file is not supported.

9 inch wide

15.4 inch wide

7 inch wide

12.1 inch wide
