IP101G
Data Sheet
32/65
January 14, 2014
Copyright © 2011, IC Plus Corp.
IP101G-DS-R01
MMD register 3.20
page
MII
ROM
R/W
Description
Default
--
3.20.6
RO 10GBASE-KR EEE
1 = EEE is supported for 10GBASE-KR
0 = EEE is not supported for 10GBASE-KR
0
--
3.20.5
RO 10GBASE-KX4 EEE
1 = EEE is supported for 10GBASE-KX4
0 = EEE is not supported for 10GBASE-KX4
0
--
3.20.4
RO 1000BASE-KX EEE
1 = EEE is supported for 1000BASE-KX
0 = EEE is not supported for 1000BASE-KX
0
--
3.20.3
RO 10GBASE-T EEE
1 = EEE is supported for 10GBASE-T
0 = EEE is not supported for 10GBASE-T
0
--
3.20.2
RO 1000BASE-T EEE
1 = EEE is supported for 1000BASE-T
0 = EEE is not supported for 1000BASE-T
0
--
3.20.1
RO 100BASE-TX EEE
1 = EEE is supported for 100BASE-TX
0 = EEE is not supported for 100BASE-TX
1
--
3.20.0
RO Reserved
Ignore when read
0
MMD register 3.22
page
MII
ROM
R/W
Description
Default
EEE Wake Error Count Register
--
3.22[15:0]
RO
(SC)
EEE wake error count
Count wake time faults where IP101G fails to complete its
normal wake sequence within the time required for the specific
PHY type.
0x0000
MMD register 7.60
page
MII
ROM
R/W
Description
Default
EEE Advertisement Register
--
7.60[15:7]
RO Reserved
Ignore when read
0
--
7.60.6
RO 10GBASE-KR EEE
1 = Advertise that the 10GBASE-KR has EEE capability
0 = Do not advertise that the 10GBASE-KR has EEE capability
0
--
7.60.5
RO 10GBASE-KX4 EEE
1 = Advertise that the 10GBASE-KX4 has EEE capability
0 = Do not advertise that the 10GBASE-KX4 has EEE capability
0
--
7.60.4
RO 1000BASE-KX EEE
1 = Advertise that the 1000BASE-KX has EEE capability
0 = Do not advertise that the 1000BASE-KX has EEE capability
0
