CC1010

SWRS047

Page 9 of 152

8. RF transmit section

Parameter

Min.

Typ.

Max.

Unit

Condition

Binary FSK frequency

separation

kHz

The frequency corresponding

to the digital "0" is denoted f0,

while f1 corresponds to a

digital "1".

The frequency separation is

f1-f0. The RF carrier

frequency, fc, is then given by

fc=(f0+f1)/2.

(The frequency deviation is

given by fd=+/-(f1-f0)/2 )

The frequency separation is

programmable in 250 Hz

steps. Separations up to 65

kHz are guaranteed at 1 MHz

reference frequency. Larger

separations can be achieved

at higher reference

frequencies

Output power

433 / 868 MHz

-20

10/4

dBm

Delivered to single-ended 50

Ω load.

The output power is

programmable, see page 123

RF output impedance

433 / 868 MHz

140/80

Ω

Transmit mode, optimum load

impedance. For matching

details see “Input/ output

matching” p.120

Harmonics

nd harmonic, 433 / 868 MHz

rd harmonic, 433 / 868 MHz

-7/-15

-27/-29

dBm

Conducted measur at

maximum output power. An

external LC filter should be

used to reduce harmonics

emission to comply with SRD

requirements. See p.128

Table 7. RF transmit characteristics
