background image
CC1010
SWRS047
Page 21 of 152
Internal RAM
Accessible
through Direct
and Indirect
Addressing
0x00
0x7F
Special Function
Registers (SFR),
accessible
through Direct
Addressing
0xFF
Accesible
through indirect
addressing
0x7FF
Internal RAM / SFR
External RAM
0x00
Flash Program
Memory
0x00
Accesible
through indirect
addressing
0x7FFF
Figure 3. Memory Map
DPL0 (0x82) - Data Pointer 0, low byte
Bit
Name
R/W
Reset value
Description
7:0
DPL0(7:0)
R/W
0x00
Data Pointer 0, low byte
DPH0 (0x83) - Data Pointer 0, high byte
Bit
Name
R/W
Reset value
Description
0
DPH0(7:0)
R/W
0x00
Data Pointer 0, high byte
DPL1 (0x84) - Data Pointer 1, low byte
Bit
Name
R/W
Reset value
Description
7:0
DPL1(7:0)
R/W
0x00
Data Pointer 1, low byte
DPH1 (0x85) - Data Pointer 1, high byte
Bit
Name
R/W
Reset value
Description
7:0
DPH1(7:0)
R/W
0x00
Data Pointer 1, high byte
