Thermal Resistance

Thermal performance is directly linked to PCB design and operating environment. Therefore, close attention to

PCB thermal design is required.

Table 3. Thermal Resistance

PACKAGE TYPE1

θJA

θJC TOP

θJC BOT

UNIT

18-Lead 3mm x 3mm LFCSP-RT

44

58

8

°C/W

1

θ values are determined per JESD51 conditions.

Electrostatic Discharge (ESD)

The following ESD information is provided for handling of ESD-sensitive devices in an ESD protected area only.

Human Body Model (HBM) per ANSI/ESDA/JEDEC JS-001 Charged Device Model (CDM) per ANSI/ESDA/JEDEC JS-

002.

ESD Ratings

Table 4. LT3077, 18-Lead 3mm x 3mm LFCSP-RT

ESD MODEL

WITHSTAND THRESHOLD (V)

CLASS

HBM

2000

2

CDM

1250

C3

ESD Caution

ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can

discharge without detection. Although this product features patented or proprietary

protection circuitry, damage may occur on devices subjected to high energy ESD. Therefore,

proper ESD precautions should be taken to avoid performance degradation or loss of

functionality.
