Data Sheet
LT3077
analog.com
Rev. 0
21 of 38
TYPICAL PERFORMANCE CHARACTERISTICS
TJ = 25°C, unless noted otherwise.
Figure 52. Noise Spectral Density
Figure 53. Noise Spectral Density
Figure 54. Integrated RMS Output Noise (10Hz to 100kHz)
Figure 55. Integrated RMS Output Noise (10Hz to 100kHz)
Figure 56. Integrated RMS Output Noise (10Hz to 100kHz)
Figure 57. Output Noise (10Hz to 100kHz)
VIN = VOUT + 0.3V
VBIAS = 5V
COUT = 22µF
ILOAD = 3A
CREF = 4.7µF
VOUT = 0.5V
VOUT = 1V
VOUT = 3.3V
FREQUENCY (Hz)
10
100
1k
10k
100k
1M
10M
0.1
1
10
100
1k
VIN = 1.3V
VBIAS = 5V
VOUT = 1V
ILOAD = 3A
CREF = 4.7µF
COUT = 10µF
COUT = 22µF
FREQUENCY (Hz)
10
100
1k
10k
100k
1M
10M
0.1
1
10
100
1k
VIN = 1.3V
VOUT = 1V
VBIAS = 3.3V
CREF = 4.7µF
COUT = 22µF
LOAD CURRENT (A)
0
0.5
1.0
1.5
2.0
2.5
3.0
0
0.4
0.8
1.2
1.6
2.0
VIN = VOUT + 0.3V
IOUT = 3A
VBIAS = 5.5V
CREF = 4.7µF
COUT = 22µF
OUTPUT VOLTAGE (V)
0
1
2
3
4
5
0
0.4
0.8
1.2
1.6
2.0
VIN = 1.3V
IOUT = 3A
VOUT = 1V
VBIAS = 5.5V
COUT = 22µF
REF PIN CAPACITANCE (µF)
0.01
0.1
1
10
100
0
0.8
1.6
2.4
3.2
4.0
VIN = 1.3V
VOUT = 1V
CREF = 4.7µF
COUT = 22µF
ILOAD = 3A
1ms/DIV
5µV/DIV
A N A L O G D E V I C E S
C O N F I D E N T I A L
