Data Sheet
LT3077
analog.com
Rev. 0
22 of 38
TYPICAL PERFORMANCE CHARACTERISTICS
TJ = 25°C, unless noted otherwise.
Figure 58. Output Noise (0.1Hz to 10Hz)
Figure 59. Startup Time
Figure 60. IN Pin Line Transient
Figure 61. BIAS Pin Line Transient
Figure 62. Load Transient
Figure 63. Load Transient
VIN = 1.3V
VOUT = 1V
CREF = 4.7µF
COUT = 22µF
ILOAD = 3A
1s/DIV
5µV/DIV
VBIAS = 2.5V
VIN = 1.2V
VOUT(NOM) = 1V
OUTPUT SETTLING TO 1%
RLOAD = 333.33mΩ
RLOAD = 100Ω
REFERENCE CAPACITANCE (µF)
0.1
1
10
100
0.01
0.1
1
10
100
VOUT = 1V
VBIAS = 3.5V
COUT = 10µF
CREF = 4.7µF
tRISE = tFALL = 1µs
VIN STEP FROM 1.3V TO 1.35V
20µs/DIV
IN TRANSIENT
AC-COUPLED
50mV/DIV
OUT TRANSIENT
AC-COUPLED
500µV/DIV
ILOAD = 50mA
VOUT = 1V
VIN = 1.3V
COUT = 10µF
CREF = 4.7µF
tRISE = tFALL = 1µs
VBIAS STEPS FROM 3.3V TO 3.8V
20µs/DIV
BIAS TRANSIENT
AC-COUPLED
500mV/DIV
OUT TRANSIENT
AC-COUPLED
1mV/DIV
ILOAD = 50mA
VOUT = 1V
VIN = 1.3V
VBIAS = 3.8V
CREF = 4.7µF
tRISE = tFALL = 100ns
IOUT STEP FROM 300mA TO 3A
COUT = 22µF
5µs/DIV
VOUT
AC-COUPLED
50mV/DIV
IOUT
2A/DIV
VOUT = 1V
VIN = 1.3V
VBIAS = 3.8V
CREF = 4.7µF
tRISE = tFALL = 100ns
IOUT STEP FROM 300mA TO 3A
COUT = 10µF
5µs/DIV
VOUT
AC-COUPLED
50mV/DIV
IOUT
2A/DIV
