FT600Q-FT601Q IC DatasheetDatasheet

Version 1.04

Document No.: FT_001118

Clearance No.: FTDI#424

Appendix A – References

Document References

Useful Application Notes

AN_370 - FT600 Configuration Programmer User Guide

AN_379 D3XX Programmers Guide

AN_375 FT600 Data Loopback Application User Guide

Modules Datasheet

DS_UMFT60xx module datasheet

Data Loopback Application

FT600DataLoopback

Acronyms and Abbreviations

Terms

Description

ADC

Analog To Digital Converter

BCD

Binary Coded Decimal

DAC

Digital To Analog Converter

ESD

Electro Static Discharge

FIFO

First In First Out

FPGA

Field Programmable Gate Array

GPIO

General Purpose Input Output

LDO

Low Drop Out regulator

PLD

Programmable Logic Device

QFN

Quad Flat Non-leaded package

RoHS

Restriction of Hazardous Substances Directive

USB

Universal Serial Bus

VQFN

Very Thin Quad Flat Non-Leaded Package
