Perfect for Lead-Free Hand Soldering

Themostimportanttechnicalchallengeoflead-freehand

solderingisbeingabletosolderheatsensitive

componentsat215-220ºC,withoutcausingdamage.

Thisrequiresasolderingironthatcanrespondtothe

thermalenergydemandsoftheapplicationand

deliverthecorrectamountofenergytothejoint

withoutovershootthatcancausedamage.

OKInternationalʼsPS-800ESolderingSystemis

perfectforlead-freesoldering.SmartHeat®

Technologyallowsthehigherthermal

performancerequirementsoflead-freealloysto

bemetwithoutincreasingthetiptemperature.

Thus,theriskofthermaldamageiseliminated.

ThePS-800ESolderingSystemallowsoperatorstoproduce

highqualityproductquickly,easilyandsafely.Itisareliable,

hassle-freeproductiontoolthatcanbeusedotsolderlead-free

PCBsimmediatelywithoutneedingtobecontinuallyre-calibratedto

meethighertemperaturerequirementsliketraditionaltechnologies.

PS-800E High Power Soldering System

Part No.

Description

PS-800E

PS-800EHighPowerSolderingSystem

Includes

PS-PW1

PowerSupply

WS2

AutosleepWorkstandwithSpongeandBrass

CleaningPad

PS-HC2

PS-800ESolderingHandlewithPS-CA2

HighPowerCoilAssemblyforSFVtips

PS-800 Soldering System

sameasabovebut

suppiedwithPS-HC1SolderingHandlewithPS-CA1CoilAssembly

forPHTTips

Specifications

Power Supply

AmbientOperatingTemperature

10-40ºC

MaximumEnclosureTemperature 65ºC

InputLineVoltage

90-240VAC

InputLineFrequency

50/60Hz

PowerConsumption

50Wattsmax.

OutputPower

35Wattsmax.at

22ºCambienttemperature

OutputFrequency

470KHz

PowerCord(3-wire)

183cm(72")

Dimensions(WxDxH)

70mmx161mmx100mm

(2.76"x6.34"x3.94")

Now comes with NEW

Auto Sleep Workstand

for improved tip life.

See accessories and

Lead-Free upgrades on

page 27.

PS-800E uses SFV tips, see pages 19-20

PS-800 uses PHT tips, see pages 20-21

PS-CA2CoilAssemblyandSFVtip(PS-800E)

PS-CA1CoilAssemblyandPHTtip(PS-800)
