ADL8201

OUTLINE DIMENSIONS

Legal Terms and Conditions

Information furnished by Analog Devices is believed to be accurate and reliable "as is". However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of

patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or

patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners. All Analog Devices products contained herein are subject to release and

availability.

analog.com

Rev. 0 | 13 of 13

Package Drawing Option

Package Type

Package Description

CP-8-30

LFCSP

8-Lead Lead Frame Chip Scale Package

For the latest package outline information and land patterns (footprints), go to Package Index.

ORDERING GUIDE

Model1, 2

Temperature Range

Package Description

Packing Quantity

Package Option

ADL8201ACPZN

−55°C to +125°C

8-Lead LFCSP, 2mm × 2mm × 0.85mm

Tape, 1

CP-8-30

ADL8201ACPZN-R7

−55°C to +125°C

8-Lead LFCSP, 2mm × 2mm × 0.85mm

Reel, 3000

CP-8-30

1 Z = RoHS Compliant Part.

2 The lead finish of the ADL8201ACPZN and ADL8201ACPZN-R7 is nickel palladium gold.
