SSM3582A
Data Sheet
Rev. A | Page 30 of 58
STANDALONE OPERATION
The SSM3582A can be operated in a standalone hardware
control mode without any I2C control. The same ADDRx pins
used to set the I2C device address are used to set the
functionality of the device. In standalone mode, the I2C pins
(SCL and SDA) are inputs and are shorted to DVDD or AGND
to set the TDM slot/sample rate of the device (see Table 18). In
this case, the ANA_GAIN bits are set to 11 and SPWDN is set
to 0 by default.
In standalone mode, TDM slot selection, mono mode operation,
and sample rate are selected via different pin settings. The
device monitors the FSYNC signal and, if it is a 50% duty cycle,
uses I2S settings. If the FYSNC signal is a pulse, the device uses
TDM settings.
Table 18. Standalone Mode Pin Settings and Functionality
Sample Rate
Pin States
TDM Slot(s)
MONO Bit
ADDR0
ADDR1
SDA
SCL
32 kHz to 48 kHz
0
Open
0
0
1, 2
0
1
Open
0
0
3, 4
0
Pull-down
Open
0
0
5, 6
0
Pull-up
Open
0
0
7, 8
0
Open
0
0
0
9, 10
0
Open
1
0
0
11, 12
0
Open
Pull-down
0
0
13, 14
0
Open
Pull-up
0
0
15, 16
0
8 kHz to 12 kHz
Open
Open
0
0
1, 2
0
32 kHz to 48 kHz
0
Open
0
1
1
1
1
Open
0
1
2
1
Pull-down
Open
0
1
3
1
Pull-up
Open
0
1
4
1
Open
0
0
1
5
1
Open
1
0
1
6
1
Open
Pull-down
0
1
7
1
Open
Pull-up
0
1
8
1
8 kHz to 12 kHz
Open
Open
0
1
1, 2
1
64 kHz to 96 kHz
0
Open
1
0
1, 2
0
1
Open
1
0
3, 4
0
Pull-down
Open
1
0
5, 6
0
Pull-up
Open
1
0
7, 8
0
Open
0
1
0
9, 10
0
Open
1
1
0
11, 12
0
Open
Pull-down
1
0
13, 14
0
Open
Pull-up
1
0
15, 16
0
16 kHz to 24 kHz
Open
Open
1
0
1, 2
0
64 kHz to 96 kHz
0
Open
1
1
1
1
1
Open
1
1
2
1
Pull-down
Open
1
1
3
1
Pull-up
Open
1
1
4
1
Open
0
1
1
5
1
Open
1
1
1
6
1
Open
Pull-down
1
1
7
1
Open
Pull-up
1
1
8
1
128 kHz to 192 kHz
Open
Open
1
1
1, 2
0
