Data Sheet
SSM3582A
Rev. A | Page 51 of 58
Address: 0x16, Reset: 0x00, Name: FAULT_CTRL1
Left Channel Overtem perature Warning
Gain Reduction.
11: 5.625 dB gain reduction.
10: 3 dB gain reduction.
1: 1.5 dB gain reduction.
0: No gain reduction.
Right Channel Overtem perature Warning
Gain Reduction.
11: 5.625 dB gain reduction.
10: 3 dB gain reduction.
1: 1.5 dB gain reduction.
0: No gain reduction.
0
0
1
0
2
0
3
0
4
0
5
0
6
0
7
0
[7:6] RESERVED
[1:0] OTW_GAIN_L (R/W)
[5:4] OTW_GAIN_R (R/W)
[3:2] RESERVED
Table 45. Bit Descriptions for FAULT_CTRL1
Bits
Bit Name
Settings
Description
Reset
Access
[7:6]
RESERVED
Reserved.
0x0
R
[5:4]
OTW_GAIN_R
Right Channel Overtemperature Warning Gain Reduction.
0x0
R/W
0
No gain reduction.
1
1.5 dB gain reduction.
10
3 dB gain reduction.
11
5.625 dB gain reduction.
[3:2]
RESERVED
Reserved.
0x0
R
[1:0]
OTW_GAIN_L
Left Channel Overtemperature Warning Gain Reduction.
0x0
R/W
0
No gain reduction.
1
1.5 dB gain reduction.
10
3 dB gain reduction.
11
5.625 dB gain reduction.
