Display

Display type

10.1 Inch LCD capacitive touch display

Display resolution

1280 x 800

Display modes

Overlay

Stacked

Zoom

Horizontal and vertical zooming is supported in all waveform and plot views.

Interpolation

Sin(x)/x and linear

Waveform styles

Vectors, dots, variable persistence, and infinite persistence

Graticules

Movable and fixed graticules, selectable between grid, time, full, and none

Color palettes

Normal and inverted for screen captures

Individual waveform colors are user-selectable

Format

YT, XY

Language support

English, Japanese, Simplified Chinese, Traditional Chinese, French, German, Italian, Spanish, Portuguese,

Russian, Korean

Input/Output ports

USB interface

Two USB 2.0 host ports

One USB device port (providing USBTMC support)

Ethernet interface

One ethernet port, 10/100 Mb/s, and 1000 Mbps ethernet (in full duplex mode only)

Probe compensation signal

Amplitude

0 to 2.5 V

Frequency

1 kHz

Source impedance

1 kΩ

Aux out

Front panel BNC connector multiplexed with AFG out. Output can be configured to provide a positive or

negative pulse when oscilloscope triggers.
