Timebase delay range

-10 divisions to 5000s

Channel to channel deskew

range

-95 ns to +95 ns

Timebase accuracy2

± 25 ppm over any ≥1 ms interval

Trigger system

Trigger modes

Auto, normal, and single

Trigger coupling

DC, HF Reject (attenuates > 50 kHz), LF Reject (attenuates < 50 kHz), noise reject (reduces sensitivity)

Trigger holdoff range

0 s to 10 s

Trigger sensitivity

Edge type, DC coupled

Any analog input channel: the greater of 6 mV or 0.8 div

Aux In: 500 mVpp to 250 MHz

Trigger level ranges

Any input channel

±5 divisions from center of screen

Aux In

±8 V

Trigger frequency counter 3

Provides frequency readout of triggerable events.

Trigger types

Edge

Positive, negative, or either slope on any channel.

Pulse Width

Trigger on width of positive or negative pulses. Event can be time- or logic-qualified

Timeout

Trigger on an event which remains high, low, or either, for a specified time period. Event can be logic-qualified

Runt

Trigger on a pulse that crosses one threshold but fails to cross a second threshold before crossing the first

again. Event can be time- or logic-qualified

Logic

Trigger when logic pattern goes true, goes false, or occurs coincident with a clock edge. Pattern (AND, OR,

NAND, NOR) specified for all input channels defined as high, low, or don't care. Logic pattern going true can be

time-qualified

Setup/Hold

Trigger on violations of both setup time and hold time between clock and data present on any input channels

Rise/Fall

Trigger on pulse edge rates that are faster or slower than specified. Slope may be positive, negative, or either.

Event can be logic-qualified

3 Available in a future release.
