DIO7708

www.dioo.com

© 2025 Dioo Microcircuits Co., Ltd. Jiangsu

DIO7708• Rev. 2.4

Absolute Maximum Ratings

Stresses beyond those listed under the Absolute Maximum Rating table may cause permanent damage to the device. These are

stress ratings only and functional operation of the device at these or any other condition beyond those indicated in the operational

sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect

device reliability.

Symbol

Parameter

Rating

Unit

VIN

Input voltage (1)

-0.3 to 33

V

VEN

Enable voltage

-0.3 to VIN + 0.3

V

VOUT

Output voltage

-0.3 to VIN + 0.3 (max. 6)

V

TJ(MAX)

Maximum junction temperature

150

°C

TSTG

Storage temperature

-55 to 150

°C

HBM

ESD capability, human body model

±2000

V

Note:

(1) Refer to Electrical Characteristics and Application Information for safe operating area.

Recommended Operating Conditions

Recommended operating conditions are specified to ensure optimal performance to the datasheet specifications. The ratings are

obtained over an operating free-air temperature range unless otherwise specified.

Symbol

Parameter

Rating

Unit

VIN

Input voltage

2.75 to 30

V

TA

Operating free-air temperature

-40 to 105

ºC

Thermal Information

Symbol

Thermal Metric

Value

Unit

RθJA

Junction-to-ambient thermal resistance (SOT23-5)

275

°C/W

RθJA

Junction-to-ambient thermal resistance (TSOT23-5)

240

°C/W

RθJA

Junction-to-ambient thermal resistance (DFN2*2-6)

72.8

°C/W
