Temperature Sensors for Packaging Machines

E52

Accurately Measure Seal Temperature

with Sensors for Packaging Machines.

• Heat resistance (sleeve: 0 to 260°C) and direct

installation to heat bars.

• Greater flexibility in the movable section (models with 30

cores).

• Protective tubing diameter of 1 mm with ground for high-

speed response.

• Usage together with the automatic filter adjustment

function of E5D Digital Temperature Controllers is

recommended.

• New models with ferrules to help reduce wiring work have

been added to the previous models with M3 screw

connections.

Temperature Sensors for Packaging Machines

Refer to Safety Precautions for the E5CD/E5ED Digital

Temperature Controllers on page 43.

Classification

Description

Model and appearance

Temperature

range

Element

type

Conductor

type

Class

Protective

tubing

material

Terminal

type

Special models

for packaging

machines

Sheathed

thermocouple

E52-CAA

D=1 S

0 to 650°C

K (CA)

Grounded

type

2 (0.75)

ASTM316L

Exposed

lead wires
