Design Considerations

Oscillators Control

•

PwdOscA and PwdOscB signals are generated in the Clock generator and used to

control the hard blocks of oscillators A and B.

•

PwdOscA =’1’ stops OscA

•

PwdOscB =’1’ stops OscB

•

The following tables summarize the Operating modes:

Prescaler Divider

•

A hardware RESET puts the prescaler divider in the following state:

–

CKRL = FFh: F

CLK CPU = FCLK PERIPH = FOSCA/2 (Standard C51 feature)

•

CKS signal selects OSCA or OSCB: F

CLK OUT = FOSCA or FOSCB

•

Any value between FFh down to 00h can be written by software into CKRL register

in order to divide frequency of the selected oscillator:

–

CKRL = 00h: minimum frequency

CLK CPU = FCLK PERIPH = FOSCA/1020 (Standard Mode)

CLK CPU = FCLK PERIPH = FOSCA/510 (X2 Mode)

–

CKRL = FFh: maximum frequency

CLK CPU = FCLK PERIPH = FOSCA/2 (Standard Mode)

CLK CPU = FCLK PERIPH = FOSCA (X2 Mode)

IDLE MODE A

The CPU is off, OscA supplies the

peripherals, OscB can be disabled

(OscBEn = 0)

IDLE MODE B

The CPU is off, OscB supplies the

peripherals, OscA can be disabled

(OscAEn = 0)

POWER DOWN

MODE

The CPU and peripherals are off,

OscA and OscB are stopped

Table 19. Overview (Continued)

PCON.1

PCON.0

OscBEn

OscAEn

CKS

Selected Mode

Comment

PCON.1

OscAEn

PwdOscA

Comments

OscA running

1X1

OscA stopped by

Power-down mode

OscA stopped by

clearing OscAEn

PCON.1

OscBEn

PwdOscB

Comments

OscB running

1X1

OscB stopped by

Power-down mode

OscB stopped by

clearing OscBEn
