Section 10 DMA Controller (DMAC)
Rev. 2.00 Sep. 24, 2008 Page 404 of 1468
REJ09B0412-0200
Figure 10.5 shows an example of timing charts in single address mode and figure 10.6 shows an
example of operation in single address mode.
LSI
Data flow
External
address
bus
External
data
bus
DMAC
DACK
DREQ
External
memory
External device
with
DACK
Figure 10.4 Data Flow in Single Address Mode
