609 / 1504 page  Section 12 Data Transfer Controller (DTC) Rev. 2.00 Sep. 24, 2008 Page 577 of 1468 REJ09B0412-0200 Clock Address DTC activation request DTC request BB W R W Clock Address DTC activation request DTC request WW L R W Clock Address DTC activation request DTC request BB L W R W [Example 1: When an odd address and even address are specified in SAR and DAR, respectively, and when the data size of transfer is specified as word] [Example 2: When an odd address and address 4n are specified in SAR and DAR, respectively, and when the data size of transfer is specified as longword] [Example 3: When address 4n + 2 and address 4n are specified in SAR and DAR, respectively, and when the data size of transfer is specified as longword] Vector read Transfer information read Data transfer Transfer information write Vector read Transfer information read Data transfer Transfer information write Vector read Transfer information read Data transfer Transfer information write Figure 12.5 Bus Cycle Division Example |
|
