Section 14 16-Bit Timer Pulse Unit (TPU)
Rev. 2.00 Sep. 24, 2008 Page 703 of 1468
REJ09B0412-0200
Table 14.13 MD3 to MD0
Bit 3
MD3*
1
Bit 2
MD2*
2
Bit 1
MD1
Bit 0
MD0
Description
0
0
0
0
Normal operation
0
0
0
1
Reserved
0
0
1
0
PWM mode 1
0
0
1
1
PWM mode 2
0
1
0
0
Phase counting mode 1
0
1
0
1
Phase counting mode 2
0
1
1
0
Phase counting mode 3
0
1
1
1
Phase counting mode 4
1
x
x
x
[Legend]
x:
Don't care
Notes: 1. MD3 is a reserved bit. The write value should always be 0.
2. Phase counting mode cannot be set for channels 0 and 3. In this case, 0 should always
be written to MD2.
