H8SXSLASH1663M datasheet(824/1504 Pages) RENESAS

824 / 1504 page

Section 15 Programmable Pulse Generator (PPG)

Rev. 2.00 Sep. 24, 2008 Page 792 of 1468

REJ09B0412-0200

• PCR_1

Bit

Bit Name

Initial

Value

R/W

Description

G3CMS1

G3CMS0

R/W

Group 7 Compare Match Select 1 and 0

These bits select output trigger of pulse output group 7.

00: Compare match in TPU channel 6

01: Compare match in TPU channel 7

10: Compare match in TPU channel 8

11: Compare match in TPU channel 9

G2CMS1

G2CMS0

R/W

Group 6 Compare Match Select 1 and 0

These bits select output trigger of pulse output group 6.

00: Compare match in TPU channel 6

01: Compare match in TPU channel 7

10: Compare match in TPU channel 8

11: Compare match in TPU channel 9

G1CMS1

G1CMS0

R/W

Group 5 Compare Match Select 1 and 0

These bits select output trigger of pulse output group 5.

00: Compare match in TPU channel 6

01: Compare match in TPU channel 7

10: Compare match in TPU channel 8

11: Compare match in TPU channel 9

G0CMS1

G0CMS0

R/W

Group 4 Compare Match Select 1 and 0

These bits select output trigger of pulse output group 4.

00: Compare match in TPU channel 6

01: Compare match in TPU channel 7

10: Compare match in TPU channel 8

11: Compare match in TPU channel 9
