Section 15 Programmable Pulse Generator (PPG)

Rev. 2.00 Sep. 24, 2008 Page 794 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Description

G3NOV

R/W

Group 3 Non-Overlap

Selects normal or non-overlapping operation for pulse

output group 3.

0: Normal operation (output values updated at compare

match A in the selected TPU channel)

1: Non-overlapping operation (output values updated at

compare match A or B in the selected TPU channel)

G2NOV

R/W

Group 2 Non-Overlap

Selects normal or non-overlapping operation for pulse

output group 2.

0: Normal operation (output values updated at compare

match A in the selected TPU channel)

1: Non-overlapping operation (output values updated at

compare match A or B in the selected TPU channel)

G1NOV

R/W

Group 1 Non-Overlap

Selects normal or non-overlapping operation for pulse

output group 1.

0: Normal operation (output values updated at compare

match A in the selected TPU channel)

1: Non-overlapping operation (output values updated at

compare match A or B in the selected TPU channel)

G0NOV

R/W

Group 0 Non-Overlap

Selects normal or non-overlapping operation for pulse

output group 0.

0: Normal operation (output values updated at compare

match A in the selected TPU channel)

1: Non-overlapping operation (output values updated at

compare match A or B in the selected TPU channel)
