H8SX/1663M 데이터시트(PDF) 272 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663M 데이터시트(HTML) 272 Page - Renesas Technology Corp |
|
|
272 / 1504 page  Section 9 Bus Controller (BSC) Rev. 2.00 Sep. 24, 2008 Page 240 of 1468 REJ09B0412-0200 Table 9.13 Area 6 External Interface Register Setting Interface MPXE6 of MPXCR BCSEL6 of SRAMCR Basic bus interface 0 0 Byte control SRAM interface 0 1 Address/data multiplexed I/O interface 1 0 Setting prohibited 1 1 (8) Area 7 Area 7 includes internal I/O registers. In external extended mode, area 7 other than internal I/O register area is external address space. When area 7 external address space is accessed, the CS7 signal can be output. Either of the basic bus interface, byte control SRAM interface, or address/data multiplexed I/O interface can be selected for area 7 by the MPXE7 bit in MPXCR and the BCSEL7 bit in SRAMCR. Table 9.14 shows the external interface of area 7. Table 9.14 Area 7 External Interface Register Setting Interface MPXE7 of MPXCR BCSEL7 of SRAMCR Basic bus interface 0 0 Byte control SRAM interface 0 1 Address/data multiplexed I/O interface 1 0 Setting prohibited 1 1 |
|
