THMC50
REMOTE/LOCAL TEMPERATURE MONITOR AND
FAN CONTROLLER WITH SMBus INTERFACE
SLIS090 – JULY 1999
13
POST OFFICE BOX 655303
• DALLAS, TEXAS 75265
+12 V
FAN_SPD/NTEST_IN
LM324
R1
39 k
Ω
R2
10 k
Ω
R3
100 k
Ω
Q1
IRF9620
+12 V
+
–
Figure 8. External Fan Drive Circuit Using 1/4 LM324 and P-Channel FET, Single Supply
