Freescale Semiconductor

Technical Data

1

MPC8544E Overview

This section provides a high-level overview of MPC8544E

features. Figure 1 shows the major functional units within

the device.

1.1

Key Features

The following list provides an overview of the device feature

set:

•

High-performance, 32-bit core enhanced by

resources for embedded cores defined by the Power

ISA, and built on Power Architecture® technology:

— 32-Kbyte L1 instruction cache and 32-Kbyte L1

data cache with parity protection. Caches can be

locked entirely or on a per-line basis, with

separate locking for instructions and data.

— Signal-processing engine (SPE) APU (auxiliary

processing unit). Provides an extensive

instruction set for vector (64-bit) integer and

fractional operations. These instructions use both

the upper and lower words of the 64-bit GPRs as

they are defined by the SPE APU.

Document Number: MPC8544EEC

Rev. 5, 01/2011

Contents

1. MPC8544E Overview . . . . . . . . . . . . . . . . . . . . . . . . . .1

2. Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . .8

3. Power Characteristics . . . . . . . . . . . . . . . . . . . . . . . . .13

4. Input Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

5. RESET Initialization . . . . . . . . . . . . . . . . . . . . . . . . . .16

6. DDR and DDR2 SDRAM . . . . . . . . . . . . . . . . . . . . . .16

7. DUART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

8. Enhanced Three-Speed Ethernet (eTSEC),

MII Management . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

9. Ethernet Management Interface Electrical

Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

10. Local Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

11. Programmable Interrupt Controller . . . . . . . . . . . . . .55

12. JTAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

13. I2C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

14. GPIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

15. PCI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

16. High-Speed Serial Interfaces (HSSI) . . . . . . . . . . . . .63

17. PCI Express . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

18. Package Description . . . . . . . . . . . . . . . . . . . . . . . . . .81

19. Clocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

20. Thermal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

21. System Design Information . . . . . . . . . . . . . . . . . . .105

22. Device Nomenclature . . . . . . . . . . . . . . . . . . . . . . . .114

23. Document Revision History . . . . . . . . . . . . . . . . . . .116

MPC8544E PowerQUICC III

Integrated Processor

Hardware Specifications
