31 / 36 page  Minimum Maximum Maximum Command Register # Comments Decimal Decimal Hex Value Value Value Relay #1 Control Bits 40015 Bit 0: 1 = enable; 0 = disable 0 27 0 x 1B Bit 1: Relay action Relay #2 Control Bits 40016 0 = DNRG < set point 1 = DNRG > set point Relay #3 Control Bits 40017 Bit 2: Set to 0 Relay #4 Control Bits 40018 Bit 4–3: Fault Mode: 00 = De-energize 01 = Hold Bits 5–15: Set to 0 Diagnostic Bits 30019 Bit 0–7: Set to 0 Bit 8: 1 = No return signal; 0 = No error Bit 9: 1 = Ringdown error; 0 = No error Bit 10: 1 = Transducer fault; 0 = No error Bit 11: 1 = No transducer; 0 = No error Bit 12: 1 = Bad transducer; 0 = No error Bit 13: 1 = Temperature fault; 0 = No error Bit 14–15: Set to 0 (read only — functions 3 or 4) Relay #1 Force Control Bits 40020 Bit 0: Force relay to forced state 03 3 1 = enable; 0= disable (normal operation) Relay #2 Force Control Bits 40021 Bit 1: Forced relay state 1 = Energize; 0 = De-energize Relay #3 Force Control Bits 40022 Bits 2–15: Set to 0 Relay #4 Force Control Bits 40023 Level Reading 30024 Level reading (level in inches x 10) Flow/Volume Reading 30025 Flow/volume reading (x 10) 4–20 mA Reading 30026 4–20 mA reading (x 10) Range 40027 Range value (x 10) Span 40028 Span value (x 10) 4–20 mA Force 40029 Loop value for loop diagnostics (x 10) 35 220 0 x DC 4 mA Point 40030 4 mA Point (level in inches x 10) 0 4800 0 x 12C0 20 mA Point 40031 20 mA point (level in inches x 10) 0 4800 0 x 12C0 Relay #1 Off Point 40032 Point in inches (x 10) 0 4800 0 x 12C0 Relay #1 On Point 40033 Point in inches (x 10) 0 4800 0 x 12C0 Relay #2 Off Point 40034 Point in inches (x 10) 0 4800 0 x 12C0 Relay #2 On Point 40035 Point in inches (x 10) 0 4800 0 x 12C0 Relay #3 Off Point 40036 Point in inches (x 10) 0 4800 0 x 12C0 Relay #3 On Point 40037 Point in inches (x 10) 0 4800 0 x 12C0 Relay #4 Off Point 40038 Point in inches (x 10) 0 4800 0 x 12C0 Relay #4 On Point 40039 Point in inches (x 10) 0 4800 0 x 12C0 16-BIT REGISTER VALUES cont. PROGRAMMING cont. 31 Lead-Lag Relay Select Lead-Lag Relay Quantity Description 0 x 03 2 Relays 1 & 2 0 x 07 3 Relays 1, 2, & 3 0 x 0F 4 Relays 1, 2, 3, & 4 With Relay 1 set as a Fault Relay 0 x 06 2 Relay 2 & 3 0 x 0E 3 Relay 2, 3, & 4 *LEAD-LAG GROUP SIZE (REGISTER 30003, 30004) |
|
