Echotel® Model 300/301

Ultrasonic Non-Contact

Transmitter For Level/

Volume/Open Channel Flow

Software version 1.x

Instruction Manual and Parts List

TABLE OF CONTENTS

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Model Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Measurement Range Calculations . . . . . . . . . . . . . . . . . .3-4

Transducer Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Transmitter Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Electrostatic Discharge (ESD) Handling Procedure . . . . . .6

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10

Software Configuration . . . . . . . . . . . . . . . . . . . . . . . .11-23

Pre-configuration Worksheet . . . . . . . . . . . . . . . . . . . . .12

Complete Menu Structure . . . . . . . . . . . . . . . . . . . .13-14

Measured Values Menu . . . . . . . . . . . . . . . . . . . . . . . . .15

System Configuration Menus . . . . . . . . . . . . . . . . . .15-21

I/O Configuration Menu . . . . . . . . . . . . . . . . . . . . . .22-24

Advanced Configuration Menu . . . . . . . . . . . . . . . . .25-26

Diagnostics Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Modbus Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27-32

Functions and Data Format . . . . . . . . . . . . . . . . . . . . . . .28

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-31

RS-485 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32-33

Agency Approvals/

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . .34

Dimensional Specifications . . . . . . . . . . . . . . . . . . . . .34-35

Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

DESCRIPTION

The Model 300/301 is a full-featured, powerful ultrasonic

system for measurement of liquid level, volume, or open

channel flow. Available as an integral or remote mounted

transmitter, this extremely versatile system is simple to

install and calibrate.

PRINCIPLE OF OPERATION

The Model 300/301 is a versatile system that utilizes non-

contact ultrasonic technology to measure liquid levels in a

variety of applications. The system consists of a transmitter

and an ultrasonic transducer. The transducer contains a

piezoelectric crystal that has the ability to convert electrical

signals generated by the transmitter into ultrasonic pulses.

The unit operates by directing ultrasonic pulses, or sound

waves, through the air toward the liquid surface. They are

then reflected off the liquid surface as an echo, and returned

to the transducer. The piezoelectric crystal then converts the

returned echo into an electrical signal which is analyzed by

the transmitter. The elapsed time between the generation of

the ultrasonic pulse and the return echo is proportional to

the distance between the face of the transducer and the liq-

uid surface.

UNPACKING

Unpack the instrument carefully, making sure all components

have been removed from the packing material. Inspect all

components, and report any damage to the carrier within 24

hours. Check the contents of the carton, making sure it

agrees with the packing slip and the purchase order. Verify

that the model number imprinted on the nameplate matches

the number on the packing slip and the purchase order.

Report any discrepancies to the factory. Check and record

the serial number for future reference when ordering parts.

CAUTION: Please read the entire installation section

carefully prior to starting installation.
