6 / 16 page ![]() SSM2932 Data Sheet Rev. 0 | Page 6 of 16 PIN CONFIGURATION AND FUNCTION DESCRIPTIONS TOP VIEW (BALL SIDE DOWN) Not to Scale 1 A B C D 23 4 BALL A1 INDICATOR SD PGND CF2 HI-Z OUTL CPVDD SGND OUTR INL– INL+ INR+ INR– PVDD CF1 CPVSS GAIN Figure 2. Pin Configuration Table 5. Pin Function Descriptions Pin No. Mnemonic Description A1 SD Shutdown Control B1 PGND Power Ground C1 CF2 Charge Pump Flying Capacitor, Terminal 2 D1 HI-Z Output Impedance Select A2 PVDD Power Supply B2 CF1 Charge Pump Flying Capacitor, Terminal 1 C2 CPVSS Charge Pump Negative Supply D2 GAIN Gain Control A3 OUTL Left Channel Headphone Output B3 CPVDD Charge Pump Positive Supply C3 SGND Headphone Sense Ground D3 OUTR Right Channel Headphone Output A4 INL− Left Channel Inverting Input B4 INL+ Left Channel Noninverting Input C4 INR+ Right Channel Noninverting Input D4 INR− Right Channel Inverting Input |
|
|
