SSM2932

Data Sheet

Rev. 0 | Page 14 of 16

TYPICAL APPLICATION CIRCUIT

POR

GAIN

POWER

MANAGEMENT

PHONE

JACK

PGA

OUTL

SGND

OUTR

INL+

1µF

2.2µF

INL–

INR+

INR–

PGND

PVDD

GAIN

HI-Z

100nF

0.1µF

POP/

CLICK

CURRENT

LIMIT

SSM2932

Figure 30. Application Circuit (Differential Input Configuration)
