CY25200

Document Number: 38-07633 Rev. *H

Page 11 of 15

Some product offerings are factory programmed customer specific devices with customized part numbers. The Possible Configura-

tions table shows the available device types, but not complete part numbers. Contact your local Cypress FAE or Sales Representative

for more information.

Possible Configurations

Ordering Code Definitions

Ordering Information

Ordering Code

Package Type

Programming Operating Temperature Range

CY25200KFZXC

16-Pin TSSOP (Pb-free)

Field

Commercial, 0 to 70

C

CY25200KFZXCT

16-Pin TSSOP – Tape and Reel (Pb-free)

Field

Commercial, 0 to 70

C

Programmer

CY3672-USB

Programmer for Field Programmable Devices

N/A

N/A

CY3695

CY22050/CY22150/CY25200 Socket Adapter for

CY3672-USB

N/A

N/A

Ordering Code[5]

Package Type

Programming Operating Temperature Range

CY25200K-ZXCxxxw

16-Pin TSSOP (Pb-free)

Factory

Commercial, 0 to 70

C

CY25200K-ZXCxxxwT

16-Pin TSSOP – Tape and Reel (Pb-free)

Factory

Commercial, 0 to 70

C

T = Tape and Reel; blank = Tube

Custom configuration code (factory programmed device only)

Temperature: C or I or blank; C = commercial; I = industrial

X = Pb-free package

Package: Z = TSSOP; S or blank = SOIC

Programming: F = field programmable; blank = factory programmed

Device part number

Company ID: CY = Cypress

25200K

CY

(Z) X

(T)

(F)

(C) (–xxx)

Table 5. 16-pin TSSOP Package Characteristics

Parameter

Name

Value

Unit



JA

theta JA

115

C/W

Note

5. “xxx” denotes a specific device configuration, and is referred to as the “dash number”. “w” denotes the configuration revision.
