Data storage format identifier (DSFID)

M24LR04E-R

62/142

Doc ID 022208 Rev 5

Data storage format identifier (DSFID)

The data storage format identifier indicates how the data is structured in the M24LR04E-R

memory. The logical organization of data can be known instantly using the DSFID. It can be

programmed and locked using the Write DSFID and Lock DSFID commands.

15.1

CRC

The CRC used in the M24LR04E-R is calculated as per the definition in ISO/IEC 13239. The

initial register contents are all ones: “FFFF”.

The two-byte CRC is appended to each request and response, within each frame, before

the EOF. The CRC is calculated on all the bytes after the SOF up to the CRC field.

Upon reception of a request from the VCD, the M24LR04E-R verifies that the CRC value is

valid. If it is invalid, the M24LR04E-R discards the frame and does not answer to the VCD.

Upon reception of a response from the M24LR04E-R, it is recommended that the VCD

verifies whether the CRC value is valid. If it is invalid, actions to be performed are left to the

discretion of the VCD designer.

The CRC is transmitted least significant byte first. Each byte is transmitted least significant

bit first.

Table 22.

CRC transmission rules

LSByte

LSBit MSBit

MSByte

LSBit MSBit

CRC 16 (8 bits)
